Palmgren 9684510 | 12" x 36" Engine Lathe 115V 1PH

assets/images/Palmgren-150px.jpg
Availability: In Stock
Part Number: PG9684510
0 Review(s)
Write a Review
$10,909.37
  • Low prices.

    Price match guarantee

  • In-House Experts.

    We know our products

  • Easy Returns.

    Quick & Hassle Free

  • Superior Selection.

    Extensive product catalog

Palmgren 9684510 | 12" x 36" Engine Lathe 115V 1PH

Palmgren's 12" model engine lathe delivers the precision, power and versatility to handle a wide range of turning operationsnormally found in much larger machines.Heavy cast construction, smooth power transmission with helical gears, hardened and ground ways all designed to give youyears of trouble-free, precise turning.All Palmgren lathes are built and inspected to the DIN 8606 toolmakers precision lathe standard assuring accuracy andconsistent performance.The bench lathe is the right choice for turning small metal parts and is used in proto type shops, home machinists, jewelrymanufacturing, tool rooms, fabrication shops and maintenance shops.




https://www.autotoolworld.com/assets/icons/features.jpg

Palmgren - 9684510 - Features

  • Lathe Comes Standard With 3 & 4 Jaw Chucks
  • Splash Guards
  • Chuck and Tool Post Safety Guard
  • MT3 Live Center
  • Inch & Metric Gears for Threading
  • Steady Rest
  • Follow Rest
  • Work Light
  • Read our blog for more information



https://www.autotoolworld.com/assets/icons/specs.jpg

Palmgren - 9684510 - Specifications

Bed Width7-1/4"
Carriage Travel31"
Compound Travel3-11/32"
Country of OriginCN
Cross Slide Travel6-3/8"
Distance Between Centers36"
Lathes TypeGear Head
Longitudinal Feed Rates0.002 - 0.055
Model NumberD320x920
Motor HP2
Number of Spindle Speeds18
Overall Dimensions (LxWxH)66" x 30" x 56"
PhaseSingle
Spindle Bore1-1/2"
Spindle seatCamlock ASA D1-4
Swing Over Bed12"
Tailstock TaperMT 3
Tailstock Travel3-15/16"
Thread Range (In.)4 to 56
Thread Range (mm)0.4 - 7
Voltage115/230
Warranty3 Year
UPC726896845104
Unit of MeasureEach
Product Height (in)52
Product Length (in)66
Product Width (in)30
Product Weight (lbs)1245



https://www.autotoolworld.com/assets/icons/pdf.jpg

Palmgren - 9684510 - Documents and Downloads

Palmgren 9684510 ManualClick to View
