Electronic Specialties Inc 687 | Low Current Probe / Digital Multimeter Tester

Low Current Probe / Digital Multimeter

  • Low Current Probe/Multimeter
  • Type Digital
  • Parameter Measured AC/DC Voltage, AC/DC Current, Resistance, Frequency, Capacitance, Duty Cycle, Diode Test, Continuity Test
  • AC Voltage Range 0 to 400 Millivolt, 4 Volt, 40 Volt, 400 Volt, 600 Volt
  • DC Voltage Range 0 to 400 Millivolt, 4 Volt, 40 Volt, 400 Volt, 600 Volt
  • Resistance Range 0 to 400 Ohm, 4 Kilo Ohm, 40 Kilo Ohm, 400 Kilo Ohm, 4 Mega Ohm, 40 Mega Ohm
  • AC Current Range 0 to 4 Amp, 80 Amp
  • DC Current Range 0 to 4 Amp, 80 Amp
  • Frequency Range 0 to 5 Hertz, 50 Hertz, 500 Hertz, 5 Kilo Hertz, 50 Kilo Hertz, 500 Kilo Hertz, 5 Mega Hertz, 10 Mega Hertz
  • Capacitance Range 0 to 40 Nanofarad, 400 Nanofarad, 4 Microfarad, 40 Microfarad, 100 Microfarad
  • Battery Type 9 Volt
  • Inclusion (35) Test Range, (10) Test Function, 9 Volt Battery, Carrying Case
  • Continuity Test Audible Beep
  • Duty Cycle 0.5 to 99 Percent
  • Clamp Opening 1/2 Inch
  • Application Fuel Injector, Fuel Pump, Electric Motor, Battery Drain, Charging System



  • https://www.autotoolworld.com/assets/icons/features.jpg

    Electronic Specialties Inc - 687 - Features

    • With the capability of measuring down to 1 milliamp (.001 Amp), the 687 is a great tool for all low current applications
    • Especially for diagnosing parasitic drains! Clamp opening is large enough to fit over most negative battery cables
    • Applications fuel injectors, fuel pumps, electric motors, battery drains, charging systems
    • Auto Power Off
    • Auto-Ranging
    • Data Hold
    • Continuity Beep
    • Overload Protection
    • Today's technicians are testing amperage on many automotive circuits. One of the most popular amperate test is the battery drain test. The 687 can measure down to 1 milliamp. Also features expanded multimeter functions, including DC/AC Volts, Ohms, Capacitance, Frequency, Duty Cycle, Continuity & Diode test.
    • Test fuel pumps, fuel injectors, parasitic drains, primary ignition coils and lamp circuits.
    • Obtain measurements as low as 0.001 amps.
    • A range of 1 milliamp to 80 amps.
    • Current measurements can be obtained by clamping over any wire.
    • The digital multimeter can also measure AC or DC volts, resistance, continuity, frequency, duty cycle, capacitance and diodes.
    • Frequency readings can be used to test crankshaft, camshaft, MAF and MAP sensors.



    https://www.autotoolworld.com/assets/icons/overview.jpg

    Electronic Specialties Inc - 687 - Overview

    • With the capability of measuring down to 1 milliamp (.001A), the 687 is a great tool for all low current applications. Especially for diagnosing parasitic drains! Clamp opening is large enough to fit over most negative battery cables. Applications: fuel injectors, fuel pumps, electric motors, battery drains, charging systems.
    • TEST RANGES
    • DC Amps: 0-4A, 80A
    • AC Amps: 0-4A, 80A
    • DC Volts: 0-400mV, 4V, 40V, 400V, 600V
    • AC Volts: 0-400mV, 4V, 40V, 400V, 600V
    • Ohms: 0-400, 4k, 40k, 400k, 4M, 40M
    • Frequency: 0-5Hz, 50Hz, 500Hz, 5kHz, 50kHz, 500kHz, 5MHz, 10MHz
    • Capacitance: 0-40nF, 400nF, 4uF, 40uF, 100uF
    • Duty Cycle: 0-.5%-99.0%
    • Diode: Diode Test
    • Continuity: Audible Beep



    https://www.autotoolworld.com/assets/icons/information.jpg

    Electronic Specialties Inc - 687 - Additional Information

    • Continuity Test Audible Beep
    • Duty Cycle 0.5 to 99 Percent
    • Clamp Opening 1/2 Inch
    • Application Fuel Injector, Fuel Pump, Electric Motor, Battery Drain, Charging System



    https://www.autotoolworld.com/assets/icons/specs.jpg

    Electronic Specialties Inc - 687 - Specifications

    Order Part NumberES687
    Item DescriptionLow Current Probe / Digital Multimeter Tester
    Manufacturer Long NameElectronic Specialties, Inc.
    Manufacturer Part Number687
    Product Group IdES00
    Country of OriginCN
    Harmonization Code90303100
    UNSPSC41113630



    https://www.autotoolworld.com/assets/icons/pdf.jpg

    Electronic Specialties Inc - 687 - Documents and Downloads

    Electronic Specialties Inc 687 Catalog PagesClick to View
