Williams 7-630 | 1" Drive Shallow Impact Socket 6-Point 15/16", Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener.
• Designed for maximum engagement on 6 point fasteners.
• Suitable for use with pneumatic and electric impact wrenches.
• Specially heat treated for impact use to provide long life, safety, and durability.
• Size (Inches): 15/16
• OAL (Inches): 2 1/8
• Drive End Diameter (Inches): 2 1/8
• Working End Diameter (Inches): 1 19/32
• Broach Depth (Inches): 5/8
• Bolt Clearance Depth (Inches): 15/16
• Bolt Clearance Diameter (Inches): 3/4
• Nose Length (Inches): 7/8
• Uses RET RING® Number: 7-2X
• Use O-Ring / Pin: 7-1B / 7-2D

Williams - 7-630 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 7-630 - Specifications

Brand Name	Williams
Order Part Number	JHW7-630
Category	Sockets And Accessories
Length	1
Material	Metal
Product Type	Socket - Impact - Set
Size / Capacity	15/16

Williams - 7-630 - Technical Details

Male square drive	1 in
Dimensions	15/16 in
OAL (inches)	2-1/8 in
Drive End Diameter	2-1/8 in
Working End Diameter	1-19/32 in
Broach Depth	5/8 in
Bolt Clearance Depth	15/16 in
Bolt Clearance Diameter (Inches)	3/4 in
Nose Length	7/8 in
Weight (lb)	1,2 lb
