Williams 6-656 | 3/4" Drive Shallow Impact Socket 6-Point 1-3/4", Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (Inches): 1 3/4
• OAL (Inches): 2 9/16
• Drive End Diameter (Inches): 1 3/4
• Working End Diameter (Inches): 2 17/32
• Broach Depth (Inches): 1 1/32
• Bolt Clearance Depth (Inches): 1 19/32
• Bolt Clearance Diameter (Inches): 1 3/4
• Nose Length (Inches): 1 7/8
• Uses RET RING® Number: 6-1X
• Use O-Ring / Pin: 6-1A / 6-2C

Williams - 6-656 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 6-656 - Specifications

Brand Name	Williams
Order Part Number	JHW6-656
Category	Sockets And Accessories
Material	Metal
Length	3/4"
Product Type	Socket - Bit - Multi-Point
Size / Capacity	1.3/4

Williams - 6-656 - Technical Details

Male square drive	3/4 in
Dimensions	1-3/4 in
OAL (inches)	2-9/16 in
Drive End Diameter	1-3/4 in
Working End Diameter	2-17/32 in
Broach Depth	1-1/32 in
Bolt Clearance Depth	1-19/32 in
Bolt Clearance Diameter (Inches)	1-3/4 in
Nose Length	1-7/8 in
Weight (lb)	1,68 lb

Williams - 6-656 - Documents and Downloads

Williams 6-656 Specification Sheet	Click to View
Williams 6-656 Data Sheet	Click to View
