Williams 2M-611 | 3/8" Drive Shallow Impact Socket 6-Point 11 mm, Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (MM): 11
• OAL (Inches): 1 1/32
• Drive End Diameter (Inches): 11/16
• Working End Diameter (Inches): 21/32
• Broach Depth (Inches): 9/32
• Bolt Clearance Depth (Inches): 19/32
• Bolt Clearance Diameter (Inches): 11/32
• Nose Length (Inches): 9/16

Williams - 2M-611 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 2M-611 - Specifications

Brand Name	Williams
Order Part Number	JHW2M-611
Category	Sockets And Accessories
Length	3/8"
Material	Metal
Product Type	Socket - Bit - Multi-Point
Size / Capacity	11.0 mm

Williams - 2M-611 - Technical Details

Male square drive	3/8 in
Dimensions	11 mm
OAL (inches)	1-1/32 in
Drive End Diameter	11/16 in
Working End Diameter	21/32 in
Broach Depth	9/32 in
Bolt Clearance Depth	19/32 in
Bolt Clearance Diameter (Inches)	11/32 in
Nose Length	9/32 in
Weight (lb)	0,07 lb

Williams - 2M-611 - Documents and Downloads

Williams 2M-611 Specification Sheet	Click to View
Williams 2M-611 Data Sheet	Click to View
