Williams 2M-609 | 3/8" Drive Shallow Impact Socket 6-Point 9 mm, Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (MM): 9
• OAL (Inches): 1 1/32
• Drive End Diameter (Inches): 11/16
• Working End Diameter (Inches): 9/16
• Broach Depth (Inches): 9/32
• Bolt Clearance Depth (Inches): 9/16
• Bolt Clearance Diameter (Inches): 11/32
• Nose Length (Inches): 17/32

Williams - 2M-609 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 2M-609 - Specifications

Brand Name	Williams
Order Part Number	JHW2M-609
Category	Sockets And Accessories
Material	Metal
Length	3/8"
Product Type	Socket - Bit - Multi-Point
Size / Capacity	9mm

Williams - 2M-609 - Technical Details

Male square drive	3/8 in
Dimensions	9 mm
OAL (inches)	1-1/32 in
Drive End Diameter	11/16 in
Working End Diameter	9/16 in
Broach Depth	9/32 in
Bolt Clearance Depth	9/16 in
Bolt Clearance Diameter (Inches)	11/32 in
Nose Length	9/32 in
Weight (lb)	0,06 lb

Williams - 2M-609 - Documents and Downloads

Williams 2M-609 Specification Sheet	Click to View
Williams 2M-609 Data Sheet	Click to View
