Williams 17-646 | 1" Drive Deep Impact Socket 6-Point 1-7/16", Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (Inches): 1 7/16
• OAL (Inches): 3 1/4
• Drive End Diameter (Inches): 2 1/8
• Working End Diameter (Inches): 2 1/4
• Broach Depth (Inches): 29/32
• Bolt Clearance Depth (Inches): 2 3/32
• Bolt Clearance Diameter (Inches): 1 13/32
• Nose Length (Inches): 2 1/4
• Uses RET RING® Number: 7-2X
• Use O-Ring / Pin: 7-1B / 7-2D

Williams - 17-646 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 17-646 - Specifications

Brand Name	Williams
Order Part Number	JHW17-646
Category	Sockets And Accessories
Length	1
Product Type	Socket - Impact - Set
Material	Metal
Size / Capacity	1.7/16

Williams - 17-646 - Technical Details

Male square drive	1 in
Dimensions	1-7/16 in
OAL (inches)	4 in
Drive End Diameter	2-1/8 in
Working End Diameter	2-1/4 in
Broach Depth	2-3/16 in
Bolt Clearance Depth	2-27/32 in
Bolt Clearance Diameter (Inches)	1 in
Nose Length	2-3/16 in
Weight (lb)	2,47 lb

Williams - 17-646 - Documents and Downloads

Williams 17-646 Specification Sheet	Click to View
Williams 17-646 Data Sheet	Click to View
