Williams 17-6152 | 1" Drive Deep Impact Socket 6-Point 4-3/4", Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (Inches): 4 3/4
• OAL (Inches): 6 3/4
• Drive End Diameter (Inches): 3 1/4
• Working End Diameter (Inches): 6 5/8
• Broach Depth (Inches): 2 29/32
• Bolt Clearance Depth (Inches): 4 29/32
• Bolt Clearance Diameter (Inches): 3 1/2
• Nose Length (Inches): 5 3/4
• Use O-Ring / Pin: 7-1C - 7-2F

Williams - 17-6152 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 17-6152 - Specifications

Brand Name	Williams
Order Part Number	JHW17-6152
Category	Sockets And Accessories
Length	1
Material	Metal
Product Type	Socket - Impact - Set
Size / Capacity	4.3/4

Williams - 17-6152 - Technical Details

Male square drive	1 in
Dimensions	4-3/4 in
OAL (inches)	6-3/4 in
Drive End Diameter	3-1/4 in
Working End Diameter	6-5/8 in
Broach Depth	2-29/32 in
Bolt Clearance Depth	4-29/32 in
Bolt Clearance Diameter (Inches)	3-1/2 in
Nose Length	2-29/32 in
Weight (lb)	33,37 lb
