Williams 17-6144 | 1" Drive Deep Impact Socket 6-Point 4-1/2", Black Industrial Finish

Supertorque lobular openings for greater turning power without deforming the fastener

Designed for maximum engagement on 6 point fasteners

Suitable for use with pneumatic and electric impact wrenches

Specially heat treated for impact use to provide long life, safety, and durability

• SUPERTORQUE® lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches
• Specially heat treated for impact use to provide long life, safety, and durability
• Size (Inches): 4 1/2
• OAL (Inches): 7
• Drive End Diameter (Inches): 2 3/8
• Working End Diameter (Inches): 6
• Broach Depth (Inches): 2 3/4
• Bolt Clearance Depth (Inches): 5
• Bolt Clearance Diameter (Inches): 3 1/8
• Nose Length (Inches): 6
• Use O-Ring / Pin: 7-1B / 7-2D

Williams - 17-6144 - Features

• Supertorque lobular openings for greater turning power without deforming the fastener
• Designed for maximum engagement on 6 point fasteners
• Suitable for use with pneumatic and electric impact wrenches

Williams - 17-6144 - Specifications

Brand Name	Williams
Order Part Number	JHW17-6144
Category	Sockets And Accessories
Length	1
Material	Metal
Product Type	Socket - Impact - Set
Size / Capacity	4.1/2

Williams - 17-6144 - Technical Details

Male square drive	1 in
Dimensions	4-1/2 in
OAL (inches)	7 in
Drive End Diameter	2-3/8 in
Working End Diameter	6 in
Broach Depth	2-3/4 in
Bolt Clearance Depth	5 in
Bolt Clearance Diameter (Inches)	3-1/8 in
Nose Length	2-3/4 in
Weight (lb)	26,83 lb
