Milton 134 | Safety Blo-Gun with 15 in Extension

Safety blow gun with 15" angled extension is OSHA compliant as it limits pressure to 30 PSI when dead ended. Offers a maximum of 150 PSI on regulated compressed air lines. Blo Gun offers 4.5 SCFM at 100 PSI. This extension is perfect for those hard to reach places. Has a 1/4" NPT air inlet and a nozzle thread size of 1/2" - 27.

Milton Industries - 134 - Features

• OSHA compliant - Four safety by-pass holes allow air to escape if end is blocked
• By-pass holes do not interfere with normal air flow
• Discharges same air volume as full-flow blo-guns, while
• maintaining nozzle pressure
• Made in USA
• Extended Safety Blow Gun
• Inlet Size 1/4 Inch
• Inlet Connection Threaded
• Body Material Zinc Alloy
• Air Consumption 4.5 SCFM at 100 PSI
• Pressure Rating 150 PSI
• Application Long Reach Application
• Applicable Standard OSHA, UL
• Nozzle Thread Size 1/2 Inch-27 TPI
• Nozzle Length 15 Inch Angled
• Maximum inlet pressure: 150 PSI
• SCFM 5.5 @ 100 PSI
• 1/4" NPT air inlet, nozzle thread 1/2"-27
• Zinc alloy body
• OSHA compliant.
• Classified by UNDERWRITERS LABORATORIES to comply with safety & health standards of Walsh-Healy act sections 50-204.8 nozzle pressure, and 50.204 noise level to comply with Williams-Steiger occupational safety and health act "OSHA" section 1910.95 noise level and 1910.242 (b) nozzle pressure. (With maximum inlet pressure of 150 PSI)This Blo-Gun has a specially engineered internal design to allow a maximum restricted discharge of 30 PSI. Approved by-pass safety nozzle.Four safety by-pass holes allow air to escape if tip-hole is blocked. By-pass holes do not interfere with normal air flow. Special internal design permits a restricted maximum discharge of 30 PSI. Discharges same air volume as full flow blo-guns, while maintaining required noise level and nozzle pressure. Bent to a special angle to clean out blind holes and offer convenient use on long reach applications.

Milton Industries - 134 - Overview

• 1/4" national pipe thread
• 4.5 standard cubic feet per minute at 100 pounds per square inch
• Maximum pressure of 150 pounds per square inch
• Classified by UL to OSHA standards 29CFR1910.95 and 29CFR1910.242(b)
• Safety Gun, 15" Ext.

Milton Industries - 134 - Additional Information

• Nozzle Thread Size 1/2 Inch-27 TPI
• Nozzle Length 15 Inch Angled

Milton Industries - 134 - Related Products

• Milton Safety Blow Gun & 10" Extension
• Milton KWIK-CHANGEÂ Universal Tip System, Blow Gun Nozzle Set (S-168)
• Milton 1/4" NPT Lever-Style Blow Gun (Pack of 10)
• Milton 1/4" NPT Lever-Style Blow Gun & 4' Extension

Milton Industries - 134 - Specifications

Order Part Number	MI134
Item Desc	Safety Blo-Gun w/ 15 In Extension
Individual Item Quantity	1 per Pack
Manufacturer Long Name	Milton Industries, Inc.
Manufacturer Part Number	134
UPC	309373001028
Product Group Id	MI00
Country of Origin	US
UNSPSC	27131500
Short Description	Safety Gun, 15" Ext.
Number of Items in This Pack	1
Made in USA	Yes
Extension Length	15"
Manufacturer	Milton Industries Inc.
Material Type	No
Display on Bloguns CMS Page	No
SCFM	SCFM 4.5 @ 100 PSI
Maximum PSI	150 PSI
Maximum Pressure	Max Pressure 150 PSI
Air inlet NPT size	1/4" NPT Air Inlet
Type of connection	1/4" NPT
Height	0.875
Width	3
Length	17.25
Style	No
Blo Gun Body material	Zinc alloy body
