JPW Industries MDL-PH19 | Reciprocating Hammer PH-19

The PH-19 metal-shaping hammer offers a compact, economical way to shape metal fast. This reciprocating hammer can do almost everything a larger model can: shrink, dome, edge turn, bead, and offset.

JPW Industries - MDL-PH19 - Features

• Delivers enough force to shape 16 gauge mild steel.
• 19” throat allows you get deep into panels and covers most metal shaping projects.
• Runs at a fixed 1,700 beats per minute. We also offer a Variable-Speed Power Hammer.
• Plug it into any 110-volt power outlet.
• Quick-release tooling handle lets you start in the middle of a panel while keeping the pressure constant.
• Tooling changes take just a few seconds and don’t require any hand tools
• .Wide variety of tooling available for shrinking, stretching, planishing, and drastic metal shaping.
• Heavy ½” plate steel frame and rigid steel stand enable this power hammer to hit with full force and prevent deflection.
• Small footprint saves space in smaller shops.
• Wheels on the base make it easy to move out of the way.
• Recommended for: Small automotive and airplane shops with limited space and/or budgets, as well as schools and educational institutions.

JPW Industries - MDL-PH19 - Specifications

Brand Name	JPW Industries
Item Description	Reciprocating Hammer PH-19
Stock Number	BA9-MDL-PH19
Aluminum Capacity (Gauge)	12.0000
Input Power	110 volt
Mild Steel Capacity (Gauge)	16.0000
Model Number	PH-19
Prop 65	Cancer and Reproductive Harm
Range of Speeds	0 - 1700 beats / minute
Shipping Dimensions (L x W x H) (In.)	60x44x70
Throat Depth (In.)	19"
Warranty	1 Year
Gross Weight	715.0
Net weight	715.0
Tooling Height Adjustment (In.)	5
