JPW Industries 1017830 | Power Feeder - PF-1850

Safety should always be one of the main concerns when woodworking and a power feeder and a power feed is one of the easiest ways to ensure that you keep your hands away from cutting edges. The PF-1850 power feeder is an all-purpose feeder that may be mounted for use with various fences and wood machinery such as shapers. The PF-1850 is designed to keep your workpiece as stable as possible using our roller spring suspension, that generates friction and pressure on the workpiece. Workpieces with minor variations in thickness of up to 3/4” are easily compensated via a roller spring mechanism.

JPW Industries - 1017830 - Features

• When mounted with the include universal mount this powerful feeder uses a continuous duty 1/4 horsepower motor provides the feed, ensuring that your feed rate is consistent and reliable. The PF-1850 has 4 speed settings can easily be changed depending on your requirements.

JPW Industries - 1017830 - Product Categories

• Baleigh Industrial
• Woodworking
• Power Feeders

JPW Industries - 1017830 - Specifications

Brand Name	Baleigh (JPW Industries)
Manufacturer Part Number	1017830
Item Description	Power Feeder - PF-1850
Item Number	PF-1850
Shipping Weight	73lbs
Speeds	20, 26, 33, 43 fpm
Power	220V Single Phase
Horse Power	1/4
Weight (lbs)	80 lbs
Rotation	Forward and Reverse
Rollers	3
Roller Diameter	3-1/8"
Roller Width	1-3/16"
Roller Travel	3/4"
Shipping Dimensions (Inches)	23x23x11
