JPW Industries 1017650 | Air Filtration System - AFS-1600

If you’re a medium to large woodworking shop or cabinet makerr, then the AFS-1600 air filtration system is perfect for you. It features three speeds and a heavy-duty 1/2 HP motor produces a maximum 1575 cfm unrestricted airflow and provides 1370 cfm of filtered air. This will clean the air in a 45’x 45’ shop every 10 minutes. This woodshop air filtration system will remove 99-percent of dust particles as small as five microns and 91-percent of particles as small as one micron in size. And the best part is that it is 110 volt and only takes 6 amps of power to run.

JPW Industries - 1017650 - Features

• For ease and convenience, the AFS-1600 air purifier for wood shops, like all Baileigh air filtration systems, comes standard with a radio frequency (RF) remote control allows you to operate the Air-Tech HP from anywhere in the shop, even from an adjacent room. The convenient RF remote is equipped with three speeds and a timer function that allows you to set a timer for 2, 4, 6, and 8 hour increments.

JPW Industries - 1017650 - Product Categories

• Baleigh Industrial
• Woodworking
• Air Filtration

JPW Industries - 1017650 - Specifications

Brand Name	Baleigh (JPW Industries)
Manufacturer Part Number	1017650
Item Description	Air Filtration System - AFS-1600
Item Number	AFS-1600
Filter Type	99% 5 Micron – 91% 1 Micron
Number of Filters	2
Filter Size	20" x 24"
Shipping Weight	160lbs
CFM	1,575 Max – 1370 Filtered Air
Remote Start	Radio Frequency (RF) With Timer Included
Speeds	3
Power	110V
Length	44"
Width	24"
Height	20"
Horse Power	1/2
Noise Level ( @ 3 meters)	66 Decibles
Shipping Dimensions (Inches)	48x45x27
