JPW Industries 1006157 | Engine Lathe PL-1860

With a base constructed from 100% cast iron , this precision engine lathe for sale holds exacting tolerances under the most demanding work conditions. It includes a factory-installed Mitutoyo DRO.

JPW Industries - 1006157 - Features

• 12 speeds between 80 and 2,000 rpm.
• Powerful 7.5 hp motor lets you shave heavy cuts off your parts for better surfaces, faster production, and longer tooling life.
• Mitutoyo 2-axis digital readout system makes it simple to achieve high-quality, precise results.
• This cast iron lathe is capable of making metric or standard threads.
• Precision-ground and hardened slideways move smoothly and consistently.
• Turcite-B coating on the ways offers years of protection under the most grueling turning conditions.
• Gap lathe design enables you to fit a larger diameter by removing a slide section.
• Cast iron construction keeps the lathe rigid and accurate over many years of use.
• Comes standard with:
• 3-jaw universal chuck (8”).
• Headstock chuck guard with automatic safety switch.
• 8” back plate.
• Steady rest and follow rest.
• Micrometer saddle stop.
• Integrated coolant system with a rear splash guard.
• Halogen work light.
• Emergency foot brake.
• Covered by a 1-year parts warranty.
• Replacement parts are in stock at our Wisconsin headquarters for fast shipping.
• Lifetime technical support by phone : call our team of experienced metalworkers any time.

JPW Industries - 1006157 - Product Categories

• Baleigh Industrial
• Metalworking
• Metal Lathes

JPW Industries - 1006157 - Specifications

Brand Name	Baleigh (JPW Industries)
Manufacturer Part Number	1006157
Item Description	Engine Lathe PL-1860
Item Number	PL-1860
Speed	30 – 2000 rpm
Spindle Bore	2.375"
Threads Diametrical Qty Speed	32 / 4–32 D.P.
Threads Imperial Qty Speed	40 / 2–56 T.P.I.
Threads Metric Qty Speed	53 / .4–14 mm pitch
Threads Module Qty Speed	44 / .4–7 M.P.
Spindle Taper Sleeve	Morse #4
Spindle Taper Nose	Morse #6
Tailstock Quill Dia	2.125"
Tailstock Quill Taper	Morse #4
Tailstock Quill Travel	4.75"
Compound Rest Width	4.92"
Center Length	60"
Center Height	9"
Compound Travel	5.31"
Bed Height	12.20"
Bed Length	17157
Bed Width	11.81"
Longitudinal Feeds Metric Qty Speed	40 / .032 – .640 mm / rev.
Main Motor	7.5 hp
Longitudinal Feeds Imperial Qty Speed	40 / .0012" – .0252" / rev.
Lead Screw Diameter	1.25"
Lead Screw Thread Pitch	4 T.P.I.
Max. Swing In Gap Length	6.125"
Max. Swing Over Bed	18"
Max. Swing Over Cross Slide	11.3125"
Max. Swing In Gap Dia	25.196"
Cross Feeds Imperial Qty Speed	40 / .0006" – .0126" / rev.
Cross Feeds Metric Qty Speed	40 / .015 – .320 mm / rev.
Cross Slide Travel	9"
Cross Slide Width	7.08"
Cutting Tool Max Section	.625" x .625"
Feed Rod	.708 dia.
Power	220V / 3-phase
Shipping Weight	5060lbs
Shipping Dimensions (Inches)	111x44x88
