JPW Industries 1002681 | Cyclone Dust Extractor DC-1450C

Got 4 or 5 machines, limited space, and a lot of dust? The compact DC-1450C is what you need. This 2 hp cyclone dust collector can pull 1,450 CFM.

JPW Industries - 1002681 - Features

• Takes 220-volt single-phase power , available at most shops.
• Robust 2 hp motor offers 1,450 CFM, enough suction for multiple machines at once.
• 1 micron filter prevents small particles from escaping into your shop.
• The fine filter will purify your air so you can breathe easily.
• Simply turn a handle on the steel mesh container to eliminate filter buildup and keep the CFM suction going strong.
• Cyclone design can extract finer dust than a bag-style dust collector for even clearer, safer air conditions.
• 28-gallon steel drum has a window on the side, so you can see how much dust you’ve collected.
• Dust collection drum is on wheels , helping you dump sawdust without spilling it.
• 2 suction ports (6” x 4”) hook up to accommodate small central systems.
• Comes with a grounding screw ; just attach a copper wire and touch it to PVC hose to take away the charge.
• Remote-controlled start comes in handy when you need to turn on the dust collector from across the room.
• You can set the timer to turn off automatically after hours of use.
• Low noise levels let you have a conversation around the machine without straining.
• 4 swiveling casters on the base make this a conveniently portable dust collector.
• It’s simple to assemble , usually taking 2 hours or less.
• Covered by a 1-year parts warranty.
• Includes lifetime technical support by phone from a team of reps with woodworking experience.
• Recommended for: basement shops or mid-sized shops crowded with machines.

JPW Industries - 1002681 - Product Categories

• Baleigh Industrial
• Woodworking
• Woodworking Dust Collectors

JPW Industries - 1002681 - Specifications

Brand Name	Baleigh (JPW Industries)
Manufacturer Part Number	1002681
Item Description	Cyclone Dust Extractor DC-1450C
Item Number	DC-1450C
Shipping Weight	295lbs
CFM	1450
Dust Collection Port	6" x 4"
Number of Outlets	2
Drum Capacity (Gallon)	28
Remote Start	Yes
Power	220V Single Phase
Horse Power	2
Noise Level ( @ 3 meters)	76 dB
Shipping Dimensions (Inches)	48x45x46
